| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 8400 | EL | 3 | = 3000°K (CRI >80) | 040 | GL | = on/off | ||||
| 4 | = 4000°K (CRI >80) | 058 | GD | = dali | ||||||
| 5 | = 5000°K (CRI >80) | 065 | D1 | = dali + em. 1h | ||||||
| 9 | = 4000°K (CRI >90) | 080 | G1 | = em. 1h | ||||||
| 090 | G3 | = em. 3h | ||||||||
| 100 | VA | = acid-etched glass | ||||||||
| 118 | GR | = radar sensor on/off | ||||||||
| 130 | ||||||||||
| 140 | ||||||||||
| 150 | ||||||||||
| 170 | ||||||||||
| 190 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8400EL4040GL | 40 | 4000°K - CRI>80 | on/off | 5521 | 138 | 365 | 150 | 5.5 | ||||
| 8400EL4058GL | 58 | 4000°K - CRI>80 | on/off | 9041 | 156 | 365 | 150 | 5.5 | ||||
| 8400EL4065GL | 65 | 4000°K - CRI>80 | on/off | 10055 | 155 | 365 | 150 | 5.5 | ||||
| 8400EL4080GL | 80 | 4000°K - CRI>80 | on/off | 12520 | 157 | 365 | 150 | 5.5 | ||||
| 8400EL4090GL | 90 | 4000°K - CRI>80 | on/off | 13962 | 155 | 365 | 150 | 5.5 | ||||
| 8400EL4100GL | 100 | 4000°K - CRI>80 | on/off | 14894 | 149 | 365 | 150 | 5.5 | ||||
| 8400EL4118GL | 118 | 4000°K - CRI>80 | on/off | 18263 | 152 | 365 | 150 | 5.5 | ||||
| 8400EL4130GL | 130 | 4000°K - CRI>80 | on/off | 19349 | 149 | 365 | 150 | 5.5 | ||||
| 8400EL4140GL | 140 | 4000°K - CRI>80 | on/off | 20452 | 146 | 365 | 150 | 5.5 | ||||
| 8400EL4150GL | 150 | 4000°K - CRI>80 | on/off | 21140 | 141 | 365 | 150 | 5.5 | ||||
| 8400EL4170GL | 170 | 4000°K - CRI>80 | on/off | 23818 | 140 | 365 | 150 | 5.5 | ||||
| 8400EL4190GL | 190 | 4000°K - CRI>80 | on/off | 28379 | 149 | 365 | 150 | 5.5 | ||||
| 8400EL4040GD | 40 | 4000°K - CRI>80 | dali | 5521 | 138 | 365 | 150 | 5.5 | ||||
| 8400EL4058GD | 58 | 4000°K - CRI>80 | dali | 9041 | 156 | 365 | 150 | 5.5 | ||||
| 8400EL4065GD | 65 | 4000°K - CRI>80 | dali | 10055 | 155 | 365 | 150 | 5.5 | ||||
| 8400EL4080GD | 80 | 4000°K - CRI>80 | dali | 12520 | 157 | 365 | 150 | 5.5 | ||||
| 8400EL4090GD | 90 | 4000°K - CRI>80 | dali | 13962 | 155 | 365 | 150 | 5.5 | ||||
| 8400EL4100GD | 100 | 4000°K - CRI>80 | dali | 14894 | 149 | 365 | 150 | 5.5 | ||||
| 8400EL4118GD | 118 | 4000°K - CRI>80 | dali | 18263 | 152 | 365 | 150 | 5.5 | ||||
| 8400EL4130GD | 130 | 4000°K - CRI>80 | dali | 19349 | 149 | 365 | 150 | 5.5 |
