| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 8407 | S5 | 3 | = 3000°K (CRI >80) | 056 | GL | = on/off | ||||
| 4 | = 4000°K (CRI >80) | 080 | GD | = dali | ||||||
| 5 | = 5000°K (CRI >80) | 090 | D1 | = dali + em. 1h | ||||||
| 9 | = 4000°K (CRI >90) | 130 | G1 | = em. 1h | ||||||
| 140 | G3 | = em. 3h | ||||||||
| 190 | VA | = acid-etched glass | ||||||||
| 220 | ||||||||||
| 230 | ||||||||||
| 280 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8407S54056GL | 56 | 4000°K - CRI>80 | on/off | 10292 | 184 | 365 | 150 | 5.8 | ||||
| 8407S54080GL | 80 | 4000°K - CRI>80 | on/off | 14735 | 184 | 365 | 150 | 5.8 | ||||
| 8407S54090GL | 90 | 4000°K - CRI>80 | on/off | 16794 | 187 | 365 | 150 | 5.8 | ||||
| 8407S54130GL | 130 | 4000°K - CRI>80 | on/off | 22776 | 175 | 365 | 150 | 5.8 | ||||
| 8407S54140GL | 140 | 4000°K - CRI>80 | on/off | 25424 | 182 | 365 | 150 | 5.8 | ||||
| 8407S54190GL | 190 | 4000°K - CRI>80 | on/off | 32627 | 172 | 365 | 150 | 5.8 | ||||
| 8407S54220GL | 220 | 4000°K - CRI>80 | on/off | 37151 | 169 | 365 | 150 | 5.8 | ||||
| 8407S54230GL | 230 | 4000°K - CRI>80 | on/off | 38377 | 167 | 365 | 150 | 5.8 | ||||
| 8407S54280GL | 280 | 4000°K - CRI>80 | on/off | 46150 | 165 | 365 | 150 | 6.8 | ||||
| 8407S54056GD | 56 | 4000°K - CRI>80 | dali | 10292 | 184 | 365 | 150 | 5.8 | ||||
| 8407S54080GD | 80 | 4000°K - CRI>80 | dali | 14735 | 184 | 365 | 150 | 5.8 | ||||
| 8407S54090GD | 90 | 4000°K - CRI>80 | dali | 16794 | 187 | 365 | 150 | 5.8 | ||||
| 8407S54130GD | 130 | 4000°K - CRI>80 | dali | 22776 | 175 | 365 | 150 | 5.8 | ||||
| 8407S54140GD | 140 | 4000°K - CRI>80 | dali | 25424 | 182 | 365 | 150 | 5.8 | ||||
| 8407S54190GD | 190 | 4000°K - CRI>80 | dali | 32627 | 172 | 365 | 150 | 5.8 | ||||
| 8407S54220GD | 220 | 4000°K - CRI>80 | dali | 37151 | 169 | 365 | 150 | 5.8 | ||||
| 8407S54230GD | 230 | 4000°K - CRI>80 | dali | 38377 | 167 | 365 | 150 | 5.8 | ||||
| 8407S54280GD | 280 | 4000°K - CRI>80 | dali | 46150 | 165 | 365 | 150 | 6.8 | ||||
| 8407S54056D1 | 56 | 4000°K - CRI>80 | dali + em. 1h | 10292 | 184 | 365 | 150 | 5.8 | ||||
| 8407S54080D1 | 80 | 4000°K - CRI>80 | dali + em. 1h | 14735 | 184 | 365 | 150 | 5.8 |
