| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 9202 | ME | 2 | = ambra (CRI >70) | 030 | GL | = on/off | ||||
| 3 | = 3000°K (CRI >70) | 034 | MG | = virtual midnight | ||||||
| 4 | = 4000°K (CRI >70) | 040 | ||||||||
| 5 | = 5000°K (CRI >70) | 050 | ||||||||
| 056 | ||||||||||
| 075 | ||||||||||
| 105 | ||||||||||
| 120 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9202ME4030GL | 30 | 4000°K - CRI>70 | on/off | 4592 | 153 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4034GL | 34 | 4000°K - CRI>70 | on/off | 5096 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4040GL | 40 | 4000°K - CRI>70 | on/off | 6006 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4050GL | 50 | 4000°K - CRI>70 | on/off | 7487 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4056GL | 56 | 4000°K - CRI>70 | on/off | 8159 | 146 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4075GL | 75 | 4000°K - CRI>70 | on/off | 12013 | 160 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4105GL | 105 | 4000°K - CRI>70 | on/off | 14783 | 141 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4120GL | 120 | 4000°K - CRI>70 | on/off | 16294 | 136 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4030MG | 30 | 4000°K - CRI>70 | virtual midnight | 4592 | 153 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4034MG | 34 | 4000°K - CRI>70 | virtual midnight | 5096 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4040MG | 40 | 4000°K - CRI>70 | virtual midnight | 6006 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4050MG | 50 | 4000°K - CRI>70 | virtual midnight | 7487 | 150 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4056MG | 56 | 4000°K - CRI>70 | virtual midnight | 8159 | 146 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4075MG | 75 | 4000°K - CRI>70 | virtual midnight | 12013 | 160 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4105MG | 105 | 4000°K - CRI>70 | virtual midnight | 14783 | 141 | 245 | 415 | 60 | 4.5 | |||
| 9202ME4120MG | 120 | 4000°K - CRI>70 | virtual midnight | 16294 | 136 | 245 | 415 | 60 | 4.5 | |||
| 9202ME3030GL | 30 | 3000°K - CRI>70 | on/off | 4569 | 152 | 245 | 415 | 60 | 4.5 | |||
| 9202ME3034GL | 34 | 3000°K - CRI>70 | on/off | 5071 | 149 | 245 | 415 | 60 | 4.5 | |||
| 9202ME3040GL | 40 | 3000°K - CRI>70 | on/off | 5976 | 149 | 245 | 415 | 60 | 4.5 | |||
| 9202ME3050GL | 50 | 3000°K - CRI>70 | on/off | 7450 | 149 | 245 | 415 | 60 | 4.5 |
